Outcome of humeral shaft fractures
Abstract
Humeral shaft fractures represent approximately 3% of all long-bone fractures and have historically been treated successfully in a non-operative way, but surgical management is indicated in several conditions. Although there are numerous randomized clinical trials and meta-analyses that have attempted to guide surgeons, there is little evidence and no consensus as to the most suitable treatment. Every treatment has its advantages and its complications, and many factors must be considered: not only the features of the fracture, but also patient compliance and surgeon experience.
Epidemiology
Fractures of the humerus are common, comprising approximately 5 to 8% of all extremity fractures. Humeral shaft fractures account for approximately 3% of all long-bone fractures 1. The overall annual incidence is 14.5 per 100,000 per year, with a bimodal age distribution: the first peak occurs in the third decade and consists mostly of high-energy trauma male patients, and a second larger peak occurs in the eighth decade and consists mostly of low-energy female patients sustaining a simple ground level fall 2,3. Humeral shaft fractures are also a marker of severe injury in trauma patients and carry a high mortality rate 4.
Classification
Humeral shaft extends from the proximal border of pectoralis major insertion to the supracondylar ridge and fractures can be classified according to the Orthopaedic Trauma Association (OTA)/Arbeitsgemeinschaft für Osteosynthesefragen (AO) combined classification 5 as AO 12-:
-
A (simple):
- spiral
- oblique (≥ 30°)
- transverse (< 30°)
-
B (wedge):
- intact wedge
- fragmentary wedge
-
C (complex-multifragmentary):
- intact segment
- fragmentary segment
Non-operative treatment
The preferred treatment for humeral shaft fractures has historically been non-operative management. In 1977, Sarmiento et al. described conservative treatment with a functional, moldable splint which allowed early return to activity, acceptable functional outcomes and minimal morbidity 6-8. This treatment has been shown to achieve an excellent or good result in nearly 94.5% of cases with a mean time of healing of 10.7 weeks, so it has been widely accepted as the gold standard for treating humeral shaft fractures conservatively 9.
Complications of non-operative management include nonunion, malunion, persistent radial nerve deficits and joint stiffness. Major reasons for failed conservative treatment are an incorrect indication, a significant deformity and a transverse fracture pattern 7.
Delayed union or nonunion, defined as radiographic detection of delayed consolidation after 6-8 months from treatment, leads to discomfort, pain and limited function of the upper extremity 10. Transverse fracture patterns might be more prone to nonunion than oblique/spiral patterns due to less bone contact area, and bracing does not permit compression of the fracture site. In contrast, muscle and soft tissue invagination into the fracture site in oblique/spiral fractures can be the cause of nonunion while in transverse fractures it is uncommon 1,11.
Humerus is not a load bearing bone so that the deformity can be tolerated. In 1966, Klenerman reviewed 32 patients with humeral shaft fractures and noted that 20° in procurvatum or 30° of varus were the limits for the deformities to become clinically relevant. These values continue to be adopted as the acceptable radiographic parameters for bracing, including the addition of 30° of acceptable valgus deformity, 15° of acceptable rotational deformity and acceptable shortening of less than 3 cm 1,12.
Persistent radial nerve deficits are due to the obvious impossibility of surgical exploration with conservative treatment, while elbow stiffness can be favored by a long period of brace immobilization.
Patients with a significant psychiatric history had particularly poor outcomes with conservative management, probably due to poorer compliance to treatment 13 (Figs. 1A, B, C).
The decision to use functional bracing in polytrauma patients should depend on the time of expected immobilization, on the presence of additional fractures of the ipsilateral upper extremity and on the patient’s need for crutches 14.
Operative treatment
Surgical treatment is usually reserved when conservative treatment fails (irreducible fracture or unacceptable reduction, nonunion or malunion), for open fractures that require debridement and stabilization, in cases of neurovascular injury, in polytrauma, in fractures extended into the joints, in floating elbow and in patients who request the possibility of early mobilization 15,16.
The ultimate goal of fixation is rigid stabilization to allow early range of motion, protection of the neurovascular structures and preservation of the tricep function posteriorly and the elbow flexor muscles anteriorly 17,18, so knowledge of the complex neurovascular anatomy of the arm is imperative to accomplish a safe surgical approach.
Radial nerve injury after humeral shaft fractures has an overall incidence of 11.8%, representing the most common peripheral nerve injury associated with bone fractures 1,19. This high percentage is attributable to the intimate contact of the radial nerve with the periosteum of the humerus. In particular, it was found to be in direct contact with the posterior humerus from 17.1 ± 1.6 cm to 10.9 ± 1.5 cm proximal to the lateral epicondyle, while distally the nerve coursed anterior to the humerus and became protected by brachialis muscle at the level of the proximal aspect of the lateral metaphyseal flare. Thus, the risk of nerve lesion is higher in two sites, defined danger zones: at the posterior mid-shaft, where the nerve lies in contact with the humerus, and at the distal lateral humerus as it pierces the lateral intermuscular septum 20.
Early surgical exploration must be recommended in several cases such as associated vascular or severe soft tissue injury, radial nerve deficit after manipulation (secondary nerve palsy), intractable neurogenic pain suggesting nerve entrapment or compression and high suspicion of nerve laceration with spiral oblique fractures. Outside of these recommendations, expectant observation is recommended due to high rate of spontaneous recovery of the radial nerve after closed humeral shaft fractures 19,21,22.
Open reduction and plate fixation
Plate osteosynthesis allows anatomical reduction, direct viewing of the fracture site, interfragmentary compression and the chance to explore and isolate the radial nerve 15.
Adhering to basic AO principles of fracture management is important when plate fixation is performed 10. Plates can be used for direct compression fracture fixation, neutralization of lag screw interfragmentary fixation or in a bridging fashion. Direct reduction with absolute stability fixation is ideal when the morphology of the fracture allows it 1.
Compression plating seems to be the best method of treatment of humeral fracture nonunion, with advantages of stable fixation, compression of the bone stumps, protection of neurovascular elements, sparing of shoulder and elbow joint from injuries and stiffness. At the same time, direct access to nonunion site leads to resect nonunion, removing of all fibrous tissues and drilling the canal enhancing local biology 10 (Figs. 2A, B, C; Figs. 3A, B, C, D, E, F).
Plate fixation has the main disadvantage of extensive surgical dissection leading to iatrogenic injuries, such as soft tissue stripping or radial nerve damage. With the improvement of plating techniques and increasing incidence in plating management of unstable humeral shaft fractures, iatrogenic injuries to the radial nerve have been reported in 4.2 to 5.1% of cases. Multiple approaches to the posterior humerus have been described, including the anterior, anterolateral, lateral, posterior and modified posterior: radial nerve is at considerable risk in each of these approaches. Its dentification during the surgical approach allows for protection and aids in its identification in the event of a future revision surgery 17,23,24.
Gerwin et al. found that the radial nerve traversed the posterior humerus 20.7 ± 1.2 cm proximal to the medial epicondyle to 14.2 ± 0.6 cm proximal to the lateral epicondyle 25. This reference, although helpful in identification of the radial nerve’s path and useful for pre-operative planning, may not be as useful when addressing comminuted fractures, malunion/nonunion and other pathologic conditions that cause alteration of humeral anatomy. Identification of the point of confluence between the long and lateral heads of the triceps and the triceps aponeurosis provides an easily identifiable superficial landmark along the posterior approach that can be considered adjunctive and complementary to previously cited method by Gerwin 24 (Figs. 4A, B, C, D).
Nevertheless, anatomical reduction and correct osteosynthesis are not an absolute guarantee of healing because there is no certainty of consolidation. Excessive fragment detachment, unfortunately, is frequently unavoidable in complex fractures to achieve an anatomical reduction, leading to bone resorption and nonunion. Factors that lead to a fixation failure are comminution, open fractures and mechanical instability of the implant 10.
Intramedullary nailing
Although several studies have compared the clinical outcomes of plating versus intramedullary nailing (IMN) in the treatment of humeral shaft fractures, the optimal surgical treatment remains controversial 26-28.
Hongjie Wen et al. in 2019 performed a meta-analysis to compare the efficacy and safety between antegrade IMN and plating for humeral shaft fracture, concluding that IMN may be superior to open reduction and internal fixation (ORIF) in reducing blood loss and post-operative infections, but inferior to minimally invasive plate osteosynthesis (MIPO) in nonunion rate. In the same study they found no statistically significant differences in operation time, functional results (evaluated with American Shoulder and Elbow Surgeons (ASES) score), rate of nerve injury, delayed union and need for reoperation 27 (Figs. 5A, B; Figs. 6A, B, C, D, E, F).
Nail introduction through the rotator cuff may create irreversible damage and possible limitation of shoulder mobility due to partial or complete tear of the rotator cuff (supraspinatus tendon is the most frequently involved 29), sub-acromial bursitis or not specific inflammatory changes of the acromioclavicular joint 30. Nevertheless, recent studies have demonstrated the safety of this technique, probably due to an increasing sensibilization about the problem and the consequent use of a more cautious transversal proximal surgical access followed by an accurate rotator cuff tendon reconstruction at the end of the procedure 15,29 (Figs. 7A, B, C, D).
An alternative to antegrade nailing is the use of an elastic intramedullary nail, such as Marchetti-Vicenzi nail, which, with a retrograde insertion, has proven to be useful and safe for shoulder function and, at the same time, allows a solid proximal fixation by means of a bundle of divergent pins 31 (Figs. 8A, B, C, D; Figs. 9A, B; Figs. 10A, B).
External fixation
The main indications for the use of external fixation in diaphyseal humeral fractures are open fractures, polytrauma, patients with severe soft tissues problems, gunshot wounds and pediatric fractures 15. In most cases an external fixator should be considered as a temporary treatment in following the principles of damage control orthopedics (DCO), but in selected cases it can be performed as definitive treatment with good results 32.
External fixation is the most rapid and minimally invasive technique compared to intramedullary splint and to plate synthesis and it doesn’t cause lesions to rotator cuff or elbow joint. Another advantage is mainly due to fracture hematoma retention, which is not possible with open reduction techniques 15.
One of the main features that differentiates external fixation from other methods of treatment is its ability to ensure adequate stability without excessive rigidity, which is crucial as biological stimulus for good healing of the fracture 15, but adequate stability is not always easy to obtain with mini-invasive monoaxial external fixators.
Long time of healing (due to dynamic and not anatomical fracture reduction), system encumbrance and the necessity of periodical medications can significantly limit patient compliance.
As for intramedullary nailing, close reduction does not give the possibility to explore the radial nerve that, at the same time, is at risk of injury during distal pin insertion (Figs. 11A, B, C, D, E).
Complications: radial nerve palsy
The intimate contact between the radial nerve and humeral diaphysis makes it particularly vulnerable to traction, stretching or entrapment following fracture of the middle-distal third of the humerus.
The incidence of radial nerve palsy (RNP) after a humeral shaft fracture has been estimated to be between 7 and 17%, making it the most common nerve lesion complicating long bone fractures 33.
Shao et al. published one of the largest studies on humeral fractures in 2005 and found an incidence of radial nerve paralysis of 11.8% 34.
Humeral shaft fractures associated with RNP are debilitating injuries and there is no clear consensus regarding if and when the nerve should be explored surgically. Radial nerve palsy can differ between primary or traumatic nerve injury and secondary or iatrogenic nerve injury.
Many authors have tried to identify a major cause for the incidence of radial nerve paralysis on humerus shaft fractures. Osterman et al. analyzed and compared their study with literature and identified that type A fractures are more often treated with intramedullary nail compared to type B and C fractures, which are usually treated with ORIF, with no significant difference in the time to onset of nerve recovery between fracture patterns and mean of treatment 35. Streufert et al. examined their study and showed that the use of an anterolateral approach for middle-distal third fractures led to a higher incidence of RNP than for proximal third fractures, likely due to the proximity of the nerve to the spiral groove and to its potentially difficult visualization and protection through an anterolateral approach.
Streufert et al. conclude that iatrogenic lesions of the radial nerve are not uncommon after surgical approach (12.2%) and that, even if all surgical exposures are at risk, the approach used does not seem to significantly impact rates of iatrogenic RNP 36.
In case of low-energy trauma, primary radial nerve palsy is often caused by simple nerve contusion or stretching with the nerve being found usually macroscopically intact 37,38. Early exploration of the radial nerve in primary traumatic palsy does not seem to be necessary, especially in closed fractures, where serious primary nerve damage requiring surgical repair is very rare. Earlier studies reported a high rate of spontaneous recovery in patients with primary nerve injury: a “wait and see” strategy seems to be widely accepted, recommending early nerve exploration only in special conditions, such as open fractures. If radial nerve palsy occurs with an open fracture of the humeral shaft, the nerve should be explored at the time of debridement of the wound 39,40. Many other authors think that a “wait and observe” strategy for a potentially compressed or damaged radial nerve is wrong. Mangan et al. observed thant patients were treated with expectant management had an overall nerve recovery rate of 77.2%. Failed expectant management and underwent late surgical exploration, which was defined as surgical intervention greater than 8 weeks postinjury, ultimately had a rate of recovery of only 68.1% (113/166). However, patients who underwent early surgical exploration, defined as surgical management within 3 weeks of injury, had a rate of radial nerve recovery of 89.8%. The difference in the rate of radial nerve function return of those who underwent early surgical exploration (89.8%) compared with patients who underwent expectant management (77.2%) alone was statistically significant 41. For this reason Mangan et al. suggest that, for patients suffering from primary radial nerve palsies due to humeral shaft fractures, early exploration of the nerve within 3 weeks of injury. Diagnostic US can help differentiate patients who would benefit from early nerve exploration, nerve repair, or acute tendon transfers from patients expected to have spontaneous nerve recovery. Shao et al. 3 published a systematic review in 2005 of radial nerve palsy associated with humeral shaft fractures and presented an algorithm to guide treatment. The algorithm includes US evaluation within three weeks of injury to assess the status of the radial nerve 3. If the nerve is continuous, loss of function is thought to be secondary to neurapraxia which may be managed conservatively. If the nerve is lacerated or entrapped, early surgical intervention is preferred as nerve function would not be expected to recover spontaneously 42. Rocchi et al. proposed in 2016 a diagnostic-therapeutic algorithm for the treatment of RNP in humerus shaft fractures. Surgical exploration could be initially deferred for fractures with low risk of radial nerve injury. The nerve palsy has to be followed up by neurophysiologic and clinic tests least 3 weeks after the trauma. If there are no electrophysiological changes at 6-12 weeks, a surgical exploration is recommended. The factors that determine the approach to nerve repair are the location and the duration of nerve injury 43 (Figs. 12 A, B, C; Figs. 13A, B, C).
Conclusions
Humeral shaft fractures resulting from low-energy trauma were historically treated successfully with conservative methods 8, but included a high percentage of nonunion, malunion, persistent radial nerve deficits and joint stiffness; indeed for these reasons surgical management has increased exponentially in recent years with many different techniques.
Surgical treatment is usually reserved for when conservative treatment fails, irreducible fracture or unacceptable reduction, nonunion or malunion, for open fractures that require debridement and stabilization, in cases of neurovascular injury, in polytrauma, in fractures extended into the joints, in floating elbow and in patients who necessitate early mobilization. ORIF with plate allows anatomical reduction, direct viewing of the fractures site, interfragmentary compression and the possibility to explore and isolate the radial nerve. IMN is a valid alternative technique and it can be superior to ORIF in reducing blood loss, low incidence post-operative infections, low rate of nonunion and fast healing.
One of the most frequent complications of humeral shaft fractures is radial nerve palsy, which can be a debilitant injury and there is no clear existing consensus regarding if and when the nerve should be explored surgically. RNP for low energy trauma has to be followed up by neurophysiological and clinical tests at least at 3 weeks after the trauma; after 6-12 weeks of no nerve recovery a surgical exploration is recommended.
Although there are numerous randomized clinical trials and meta-analyses that have attempted to guide the surgeon in choosing, there is little evidence and no consensus as to the most suitable treatment. There is no specific algorithm for deciding since it is necessary it is necessary to consider many factors 15.
Treatment should be determined not only on the features of the fractures, but also on the experience of the surgeon and on patient compliance.
